Studio Auditorium Hotel acoustic sound folding divider

$89.99 - 129.99 /Square Meter
Payment Type:
T/T
Incoterm:
FOB,CIF,EXW
Min. Order:
20 Square Meter
Transportation:
Ocean
Port:
GUANGZHOU,SHENZHEN
Share:
  • Product Description
Overview
Product Attributes

Model No.MQ-PARTITION

BrandMAGIC CUBE

Warranty Service5 Years

After-sales ServiceOnline Technical Support, Return And Replacement

Engineering Solution CapabilityTotal Solution For Projects

Application ScenarioHotel, Villa, Hall, Gym, Home Bar, Office Building

Design StyleContemporary, Farmhouse, Rustic, Mid-Century Modern, Chinese, Traditional, Scandinavian, European, French

Place Of OriginChina

Model NO.Movable Partitions

TypeMelamine MDF Panel, Fireproof PVC Board, Fabric

ApplicationOffice, Hotel Banquet Hall

Main MaterialAluminum Frame and Track

Soundproof MaterRock Rool , Glass Wool

Soundproof Stc40dB-50dB

DimensionsW700-1200mm, H2000-5200mm, Thickness 80-110mm

Stacking WayCentre Partiting; Side Parking

Supply Ability & Additional Information

PackagingCarton Paper Packaging, MDF Batten Cover Corners

Productivity5000sq/Month

TransportationOcean

Place of OriginCHINA

Supply Ability5000sq/Month

CertificateCE

HS Code76101000

PortGUANGZHOU,SHENZHEN

Payment TypeT/T

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners

Product Description


In the lobby of a large hotel, a large and spacious space cannot be used effectively except for large-scale events. Therefore, if it needs to be effectively used, a mMoveable Partition Wall must be used, because the Movable Partition Wall is practical and beautiful. For hotels that need to contact customers The place, the elegant and atmospheric movable partition wall is bright and pleasing to the eyes.



Specifications


Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function Hall
Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function Hall



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function Hall

Ultra high 100 type

    Ultra-high Movable Partition is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function Hall

Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function Hall

Stacking Ways

Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function HallApplications

Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function Hall
Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function Hall
Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function Hall
Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function Hall


Soundproof Soundproof Movable Partition Movable Acoustic Dividers for Multi-Function Hall

Product features of ultra-high movable partition:

1. There is no need to install rails on the ground. The partition door panels are connected to the hanging installation rails on the ceiling. The door panels rely on the ceiling rails to push and use without noise. When you need to use it, press down the bead, and the movable partition wall can be installed soon.

2. The door panel is equipped with a retractable structure up and down.

3. After the large space is divided into small spaces, the thermal insulation performance and Sound Insulation effect will be more significant.

4. They are all made of high-efficiency flame-retardant fire-resistant materials, which have good fire-proof performance and can immediately block the re-burning of the fire source. The safety factor is high, the product data meets the national standards, and the materials are environmentally friendly, energy-saving and renewable.

5. The exterior of the partition door panel can be arbitrarily designed with decorative surfaces according to the needs of customers and the style of the venue.

The ultra-high Moveable Wall is a kind of partition wall, also known as the partition wall, which is a non-load-bearing component that separates the interior space of the building. When you don't need to use it, you can fold it and put it aside to make the combined space appear wider and larger. The Moveable Wall has the characteristics of easy movement, simple operation, high sound insulation and fire protection, etc. It is especially suitable for hotels and Space separation in large buildings such as banquet halls. The design of this movable partition is equipped with a vertical compression fitting device to keep the partition in place very securely.

1. It supports partial disassembly and assembly, which can be reused many times. The material of the partition wall system adopts polymer technology materials, and it has the functions of fireproof, sound insulation and heat insulation. Because it is a green and environmentally friendly building material, it has a long service life. The materials for installing movable partition walls are cheaper and more durable than installing other forms of partition materials. Therefore, the activity partition is more cost-effective, and it is suitable for use in banquet halls, hotels and other places.


2. In a hotel or banquet hall, customer groups and customer needs determine the area of the separated space. In order to meet the office needs of enterprises in all walks of life at the same time, the large space with a single function is divided into multiple small spaces with different areas. Improve space utilization and flexibly change the size of the space.
