Firproof Interior Waterproof moveable hall partitions

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
Overview
Product Attributes

BrandMAGIC CUBE

Main ApplicationCommercial Furniture

Types OfOffice Furniture

Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce)Y

Supply Ability & Additional Information

TransportationOcean

Place of OriginCHINA

CertificateCE

HS Code 76101000

Payment TypeT/T,Others

IncotermFOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter

Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing

Product Details

Product Structure


Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding Partitions
Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding Partitions



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding Partitions

Ultra high 100 type

    Ultra-high dividers movable sliding walls is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high partition can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Dividers Movable Sliding Walls Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding Partitions

Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding Partitions

Stacking Ways

Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding PartitionsApplications

Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding Partitions
Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding Partitions
Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding Partitions
Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding Partitions


Automatic Room Dividers Acoustic Sliding Folding Partition Movable Wall Vertical Folding Partitions



The middle of the movable accordion walls is made of Sound Insulation cotton and other materials, and the surrounding frame is made of aluminum alloy material, and the sound insulation effect is as high as 53dB coefficient, which can isolate the noise of ordinary speech.

The sound insulation coefficient of the movable accordion walls comes from multiple directions, not only in the partition wall itself, but also in other links, as shown below:

1. Horizontal sound insulation

In order to achieve the best sound insulation effect, the structure of the upper and lower layers of sound insulation rubber is adopted. Using the mechanical principle of the jack, the double-layer rubber strip is tightly pressed on the track of the ceiling and the bottom of the partition fan to provide a high-stability movable partition.

2. Corner sound insulation

The use of specially made rubber for the corner components solves the technical problem of corner sealing; at the same time, this method also achieves superior stability and sound insulation.

3. Vertical sound insulation

All soundproof walls are made of particularly elastic vertical sealing sides, with concave and convex grooves closely matching to ensure the best closure and sound insulation effect.

4. Skeleton

The hanging structure based on the wall panels allows it to sway freely and freely. The metal hoops between the wall panels are closely combined with each other, which effectively blocks the transmission of sound. The partition door panel can be replaced as needed according to the interior design without destroying the entire soundproof Movable Wall dividers panel.
