HomeProductsMovable Wallsliding folding partitions movable walls
sliding folding partitions movable walls
  • sliding folding partitions movable walls
  • sliding folding partitions movable walls
  • sliding folding partitions movable walls
  • sliding folding partitions movable walls

sliding folding partitions movable walls

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
< >
Overview
Product Attributes

Brand: MAGIC CUBE

Main Application: Commercial Furniture

Types Of: Office Furniture

Whether To Support Mail Order Packaging (special Packaging For Cross-border E-commerce): Y

Supply Ability & Additional Information

Transportation: Ocean

Place of Origin: CHINA

Certificate: CE

HS Code:  76101000

Payment Type: T/T,Others

Incoterm: FOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter

Product Description


    movable doors walls is a Movable Wall with general wall functions that can divide large space into small space or connect small space into large space at any time according to needs. It can play a role of multiple functions in one hall or one room. The acoustic movable walls brings great convenience to people's work. For example, you can fold it on one side when you need it, so that the two spaces are temporarily joined to make them appear larger, which is convenient for temporary departmental meetings.

Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing

Product Details

Product Structure


High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office Partition
High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office Partition



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office Partition

Ultra high 100 type

    Ultra-high movable doors walls is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high movable interior walls can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The movable interior walls can make a turn automatically as sliding in the straight rail


High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office Partition

High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office Partition

Stacking Ways

High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office PartitionApplications

High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office Partition
High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office Partition
High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office Partition
High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office Partition


High Sound Insulation Sliding Divider Panels Partition Mobile Sliding Dividers Panels Mobile Office Partition

moveable acoustic panels Construction process:



1) Install the track

2) Install the movable panel

According to the installation method, accurately draw the pulley line on each door panel, and then fix the pulley's fixing frame to the upper or lower tower of the partition with screws; install the door panels into the track one by one in order, and adjust each door panel. , make sure they are all perpendicular to the ground. And all of them can be pushed, pulled and rotated flexibly, and finally each door panel is connected and fixed. Under normal circumstances, the adjacent door panels are connected by hinges.

3) Finishes

The decoration of the veneer should be carried out according to the requirements of the hotel interior design. Generally, soft bags, cold-installed solid wood boards, veneer panels, glass inlays, etc. will be used. The decoration and construction of the veneer shall be carried out according to the corresponding requirements of the second standard. After the veneer is finished, the painting or finishing can be carried out.

4) Debugging:

After the door panel of the moveable acoustic panels is installed, the details of the door panel should be debugged, such as the height of the door panel and the tightness of the door panel.

Wait, after debugging, clean up the site and complete all the installation work.
































Product Categories : Movable Wall
