HomeProductsMoveable Divider Wallmulti-color vertical folding partitions
multi-color vertical folding partitions
  • multi-color vertical folding partitions
  • multi-color vertical folding partitions
  • multi-color vertical folding partitions
  • multi-color vertical folding partitions
  • multi-color vertical folding partitions
  • multi-color vertical folding partitions

multi-color vertical folding partitions

$89.99 - 129.99 /Square Meter
Sound-absorbing board varieties:
Share:
  • Product Description
< >
Overview
Product Attributes

Model No.: MQ-PARTITION

Brand: MAGIC CUBE

Warranty Service: 5 Years

After-sales Service: Online Technical Support, Return And Replacement, Other

Engineering Solution Capability: Total Solution For Projects, Others

Application Scenario: Hotel, Home Bar, Home Office, Workshop, Gym, Hall, Mall

Design Style: Contemporary, Scandinavian, Eclectic, Victorian, Traditional, Postmodern, Southwestern, Japanese, Modern, Mediterranean, Craftsman, Chinese, Minimalist, Coastal, Mid-Century Modern, French, Industrial, Rustic, Transitional, Midcentury, European, Tropical, Farmhouse, Asian

Place Of Origin: China

Model NO.: Movable Partitions

Type: Melamine MDF Panel, Fireproof PVC Board, Fabric

Application: Office, Hotel Banquet Hall, etc.

Main Material: Aluminum Frame and Track

Soundproof Mater: Rock Rool , Glass Wool

Soundproof Stc: 40dB-50dB

Dimensions: W700-1200mm, H2000-5200mm, Thickness 80-110mm

Stacking Way: Centre Partiting; Side Parking

Open Way: Sliding Partition

Ransport Package: Carton Paper Packaging, MDF Batten Cover Corners

Supply Ability & Additional Information

Packaging: Carton Paper Packaging, MDF Batten Cover Corners

Productivity: 5000sq/Month

Transportation: Ocean

Place of Origin: CHINA

Supply Ability: 5000sq/Month

Certificate: CE

HS Code: 76101000

Port: SHENZHEN,GUANGZHOU

Payment Type: T/T,Others

Incoterm: FOB,CIF,EXW

Packaging & Delivery
Selling Units:
Square Meter
Package Type:
Carton Paper Packaging, MDF Batten Cover Corners
Product Description




The installation process of the sliding folding partition walls:

1. Positioning measurement. When installing sliding folding partition walls, professionals will measure according to the indoor floor plan, release the control line, and then guide the position line to the roof, and then finalize the internal marking and construction details.

2. Installation of steel structure and fixed parts. The steel structure is a load-bearing member linking the ceiling and the track, it is very important, and even involves the safety of the entire partition system. In this step, it is necessary to weld the fixed parts to death according to the requirements of the construction drawing, and at the same time carry out anti-rust treatment on all the metal parts.



Specifications

Type 65 type, 80 type, 100 type, ultra high 100 type.
Finish melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density  28~32kg/m²
STC 40db-50db
Dimensions width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure 25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing


Product Structure


Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference Room
Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference Room



Panel Suspension  Top hunge system without the need for a floor track.
Panel Width Each panel 600mm-1200mm.
Track Aluminum OR Steel Track
Roller on panel Single or double  roller.
Panel Frames  Heavy-duty steel-gusseted aluminum inner frames reinforced with  full height.
Top&bottm seals Top and bottom pressure retractable seals ensure effortless moved and locked.
Module 700mm - 1200mm maximum.
Panel stacking Numerous panel stacking options for complete flexibility.
Panel face  MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard




Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference Room

Ultra high 100 type

    Ultra-high office moveable walls is designed for movable partition as high as 6 to 17 m with max soundproof rate 50 dB. Ultra-high type partition is top hung system, hanging wheel sliding in the track smoothly and stability without vibration, the 17 meters high office moveable walls can easily moved even being pushed at waist-high. With build-in oriental device, the panel can make a turn automatically as sliding in the straight rail.

Features

  • Load bearing of each meter is more than 2000 KGS
  • Each pulley bearing more than 1500 KGS
  • Easily moved even being pushed at waist-high
  • The panel can make a turn automatically as sliding in the straight rail


Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference Room

Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference Room

Stacking Ways

Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference RoomApplications

Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference Room
Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference Room
Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference Room
Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference Room


Eco Friendly Partition Fireproof Material Automatic Operable Walls for Office Meeting Room, Conference Room

Each soundproof movable panels be equipped with one or two hanging wheels, which are equipped with delicate bearings, which can make smooth turns at 90 degrees, 180 degrees, 360 degrees and other specific angles without the need for steering gear. The retractor in the partition can be moved up and down by shaking hands, and each soundproof movable panels can also be fixed individually. Each partition wall is equipped with a fast expansion and sealing system, which makes the partition fast and is called a solid wall. , Shake the joystick to make the P1 board extend up and down, left and right, and the P2 board extend up and down, thus forming a complete partition wall.

What are the precautions for the installation of ultra-high partitions?

1) Before installation, carefully observe the overall construction environment and surrounding environment where the Movable Partition Wall needs to be installed. Investigating the site environment is the primary task, mainly to determine whether the site has the installation conditions, carefully look at the position of the beams and columns on the roof, the position of the reserved space and the position of the air-conditioning piping system, and record them one by one for the final planning. construction plan.


2) Firstly, according to the measurement results, locate and survey, and according to the requirements of the construction drawings, release the position control line of the movable partition on the indoor ground of the site, and then guide the position line of the partition wall to the side wall and the top plate. Secondly, the installation position of the fastener should be popped up when the wire is bounced again: the height of the installation must be agreed with the construction team installing the ceiling, so as to avoid too much unnecessary trouble.

FAQ

1.Can I get free samples and how long does it take to produce samples?

If the samples you need are in our stock, they will be provided to you free of charge. Customized samples usually take about a week to produce.


2. Do you accept OEM or ODM order?

Yes, as a manufacturer, we can produce acoustic materials based on your samples or drawings. Please do not hesitate to contact us.


3. How to get an accurate quotation?

Can provide us with detailed product information, such as pattern, core material, surface, etc. If you have CAD or other drawings, don't hesitate to send it to us.


4. Payment terms

T/T 30% deposit before production, 70% balanced payment before delivery.


For more information, please feel free to contact us.
